CLAVILOCK ALP Locking Titanium Superior Clavicle Plate
The clavicle osteosynthesis plate system offers a set of pre-contoured plate solutions to fit the natural S anatomical contour of the clavicle; this gives specialists the opportunity to choose the most appropriate option depending on the type of patient.
Characteristics:
– Combined holes for the use of standard screws or locking screws.
– Quality Raw Material Titanium Alloy (Ti6Al4V ELI, ASTM F136).
– Rounded profile shaft.
CLAVILOCK ALP Locking Titanium Superior Anterior Clavicle Plate
| Left (Code 143) / Right (Code 142) |
| 6, 8 and 10 Shaft Holes |
| SCREWS |
|
3.5mm Titanium Cortex Locking Screw (Code 106, Length 12mm-60mm) 3.5mm Titanium Cortex Screw (Code 112, Length 12mm-60mm) |
CLAVILOCK ALP Locking Titanium Superior Anterior Clavicle Plate with Lateral Extension
| Left (Code 141) / Right (Code 140) |
| 4, 5 and 6 Shaft Holes |
| SCREWS |
|
2.5mm Titanium Cortex Locking Screw (Code 155, Length 08mm-30mm) 3.5mm Titanium Cortex Locking Screw (Code 106, Length 12mm-60mm) 3.5mm Titanium Cortex Screw (Code 112, Length 12mm-60mm) |
